CXL rotary filter
product description
The CXL rotary filter is a commonly used solid-liquid separation equipment, used to intercept and remove small diameter suspended solids and particulate impurities in the water supply system. Scope of application Rotating screen grids are often used in water supply projects such as water plants where surface water is the source of water, and can also be used in drainage treatment projects to further remove dirt from the water source after the coarse grid. Outstanding advantages 1. The driving device is directly driven by a cycloid pin wheel or a gear reducer, with low noise, compact structure and stable operation; 2. There are three types of water inlet for the equipment: front water inlet, inner water inlet and outer water inlet; 3. The equipment is easy to operate, and can directly control the operation of the equipment locally or remotely; 4. In order to prevent external overload, it is equipped with double protection of mechanical shear pin and overcurrent, which makes the equipment operation safe and reliable. working principle The equipment adopts a rotary type, and a filter belt formed by a piece of mesh plates forms a water grid surface. When the sewage flows through, the debris larger than the grid gap is intercepted, and the filter screen rotates continuously during operation and will be intercepted on the network After the sundries are lifted to the top, the sundries are washed out into the receiving trough by pressure water for further processing. The filter screen has a strong self-cleaning ability and will not be blocked.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
